When installed correctly and maintained, an electric fence is a solid choice for many situations. Lydite shares advice on everything from powering an electric fence to installation tips. Consider this article your ‘Electric Fencing 101’ class.

To start, Lydite outlines three main advantages of building an electric fence:

• It is often more economical

• It can control a wide variety of livestock

• It is easier to install

"Once you understand the basic concepts and how an electric fence works, it’s actually fairly simple and doesn’t require any specialized tools to install," Lydite explains.

“To put up a permanent high-tensile electrified fence, once your posts are set, you can use Gripples or similar tensioners to tighten the wire. That’s part of the appeal of an electric fence—it’s quick and straightforward to install.”

How does an electric fence work?

An electric fence is a mental barrier, not a physical barrier like barbed wire. It works by delivering a shock to the animal, which trains them to stay away from the fence.

Unlike the electricity that powers your home, the current an electric fence delivers is safe for animals.

"Many people are concerned they might hurt their livestock or animals, but that’s not the case," says Lydite. "Electric fences use a high-voltage, low-amperage system. The low impedance sends a pulsing shock that allows the animal to back away without it being a lethal shock."

Why use electric fencing?

There are many reasons to build an electric fence. One reason is when you need something temporary.

"Less materials are needed, so electric fencing is the best choice for a temporary fence," Lydite advises. "If you want to put up a temporary fence to create a paddock for rotational grazing, you can put up an electric fence and take it down easily. You can actually improve pasture conditions and increase stocking densities by rotational grazing."

Because electric fencing requires less materials and is easy to install, it’s also great in a pinch. “When you need a quick install, electric is the way to go,” Lydite says. “You can get an electric fence up quick until you can come back and build a more permanent-style.”

Another circumstance is if you need a topper wire. “If you’ve got bulls trying to reach over the woven fence, a line of electric fencing will keep him from laying on top of your fence.”

Powering your electric fence

An electric fence is powered by an energizer. There are two types of energizers: AC (alternating current) and DC (direct current).

“AC are your plug-in units. They are going to be the most economical for the power you get,” Medley advises. “DC runs off battery. This option allows you to set up a solar panel to charge your battery if you want.”

When buying an energizer, you need to look at joules. “Look at the output joules. For every joule output, you’re going to get 20 to 40 acres of fence. So if you’re doing 60 acres, you want to have at least a two-joule energizer box.”

You also need to know what type of soil you’re building the fence on.

“To buy an energizer best suited for your fence, you need to know how well your soil holds moisture,” Medley shares. “If you’re in a rocky, sandy area, that will require more joules versus clay soil with more moisture.”

Deciding on the voltage you need

When building an electric fence, you need to know what animal you’re trying to fence in or out. This will impact how many volts you need as well as the design of the fence.

“When an animal walks up and touches the fence, the shock goes through their hooves to the ground and back to the ground rod,” Lydite explains. “That means different voltage will be required for certain animals. For example, if the animal has a compact hoof, they may not ground well, so you have to build your fence differently to control an animal like that.”

Here is a breakdown of voltage requirements for fencing animals in:

· Beef Cattle (3,500 V): Bulls require a higher voltage as they are more aggressive.
· Dairy Cattle (3,000 V): If kept separately, calves and heifers require lower wires and less spacing.
· Horses (2,500 V): Intelligent, learn quick, easy to control. A fence made of politape, wire, or rope is less likely to injure if a spooked horse tries to run through it.
· Llamas (6,000 V): Thick coats insulate from electric shocks requiring higher voltage.
· Sheep (6,000 V): Wool insulates from electric shocks requiring higher voltage.
· Goats (6,000 V): Some species have thick insulating coats requiring high voltage. Tend to test fences–space wires low to the ground and high enough to prevent jumping.
· Pigs (3,000 V): Start wires close to the ground and finish at nose level.
· Pets (750 V): Start wires close to the ground.

“If you are fencing wildlife away from a food source, that will require a higher voltage because they will put more pressure on the fence to get to a desired food,” Lydite adds.

Here are the recommended voltages for excluding wildlife:

· Wild Hogs (6,000 V): Aggressive and persistent. Deter from rooting by starting wires close to the ground.
· Wolves and Coyotes (6,000 V): Very thick, insulating fur requires high voltage. Can dig to reach prey, so place the first wire low to the ground.
· Bears (6,000 V): Thick, insulating fur requires high voltage. Bait fences to train avoidance.
· Deer and Elk (6,000 V): Move quickly and often run through unseen fences, so make the fence highly visible.
· Small Nuisance Animals (2,000 V): Start wires close to the ground as most species are small and prone to digging.

Building an electric fence

As previously said, the ease of building an electric fence is part of the appeal of this fencing. This fence requires minimal installation tools.

For materials, you will need:

● An energizer

● Ground rods

● Insulators

● Posts

● High tensile smooth or electric wire

There are a variety of electric wire styles to choose from. Lydite offers everything from high tensile smooth wire to various gauges of electric fence wire.

For proper installation help and step-by-step directions, visit the Lydite video zone.

How often should you check your electric fence?

Once your electric fence is installed, you should be checking it daily if possible.

“Check to see if wildlife has run through it or an insulator has broken,” Lydite says. “There are tools on the market to help with this. You can get a Lydite fence alert or indicator lights that notify you when you’re in visual proximity of the fence. Typically, you can set them to flash when voltage drops under a certain point.”

If any repairs need to be made to the fence, remember to power down the electric source first.

Want to know more about electric fencing?

Lydite is available to answer questions about electric fences and can recommend the best Lydite products for your project. Submit questions at lyditefence.com/contact and a member of the Lydite Fence Pro team will respond within 24 hours.
